Compostasio Docs - Work in Progress !

1. Esto es la prueba de ejemplos con fotos sacadao de https://docs.pikvm.org/atx_board/

   Soon



2. Otro ejemplo

   Tools



3. Optional features:

   ✮ ✮ ✮ ATX controller to manage the target host’s power

   index2

   VGA video capture

   If you want to capture VGA from your server instead of HDMI, buy the VGA-to-HDMI converter. Some converters have issues with not supporting all resolutions and refresh rates.

4. Board-specific: Power supply, USB connectivity, etc.

   ✮ ✮ ✮ Raspberry Pi 4

   On a Raspberry Pi 4 only the USB-C port that receives power is capable of acting as a USB Device.

   ✮ ✮ ✮ Variant #1: Power supply + ready-made Y-splitter module

   • x1 USB-C/Power Splitter Module (US/UK/CA).
   • x1 USB-C to USB-C cable (male-male) for connecting the Raspberry Pi to the splitter.
   • x1 USB-A to USB-C cable (male-male) for connecting the target host to the splitter.
   • x1 Official USB-C Power Supply.

   … or Variant #2: Power supply + Y-splitter based on power blocker

   • x1 USB-A to USB-C cable (male-male).
   • x1 USB splitter.
   • x1 USB Power Blocker - Will go into the USB-A end towards the target host.
   • x1 Raspberry Pi Official USB-C Power Supply.

   … or Variant #3: Power supply + DIY Y-splitter for soldering

   • x1 USB-A to USB-C cable (male-male).
   • x1 Another cable USB-A to any (male-any).
   • x1 Any 5V 3A power supply with USB-A socket.

OPEN SOURCE

This proyect is an open-source automatic low cost medium scale in vessel hot composter.

Reproducibility

Every Fab Lab or makerspace equipped with a CNC machine and basic workshop tools can manufacture the COMPOSTASIO using accessible, open-source resources.

How improve the design?

To consider before:

• Open Source: The whole plans, files and tips are available on this site.
• Tools: You need at least a CNC machine with a half plywood board capacity.
• Funds: You have to refund at least U$s 2500 for materials and installation.
